Key Features: High Efficiency: Advanced Maximum Power Point Tracking (MPPT) with up to 99.9% efficiency, ensuring maximum solar energy utilization. Robust Performance: Capable of delivering a rated output power of 6kW with a peak power of 12kVA, suitable for various power needs including motor loads up to 4HP. User-Friendly Design: Features an industrial design with a modern aesthetic, easy installation, and simple operation for user convenience. Reliable and Safe: IP65-rated enclosure for protection against dust and water, ensuring reliable operation in diverse environmental conditions. Includes comprehensive safety features from hardware to software. Powerful Charging: Supports up to 100A charging current and is compatible with multiple battery types, including lead-acid, lithium-ion, and user-defined options. Intelligent Operation: Equipped with exclusive lithium-ion battery BMS dual activation and a time-slot function to optimize energy costs by utilizing peak and off-peak rates. Technical Specifications: Rated Output Power: 6000W Maximum Peak Power: 12000VA Rated Voltage: 230V AC, single phase Frequency: 50/60Hz Battery Voltage Range: 40-60V DC (minimum start-up voltage 44V) Maximum PV Input Current: 16A 16A Maximum Utility Charging Current: 60A Maximum Efficiency: 97.5% MPPT Operating Voltage Range: 120-450V DC Enclosure Protection Rating: IP65 Dimensions: 556 x 345 x 182 mm Weight: 20 kg Operating Temperature Range: -25°C to 60°C (with derating above 45°C) Noise Level: <60dB Communication Interfaces: RS485, CAN, USB, and Dry contact, with optional WiFi/GPRS module Certifications: Safety and Compliance: Certified under IEC 62109, EN 61000, RoHS, and EN50549-1 standards. DOWNLOAD DATASHEET
